Rolling Service Doors

---

Rolling Service Door is designed to meet the tough requirements of virtually any commercial or industrial application. Model 800 offers flexibility in substrate materials with choices of galvanized or prime steel, stainless steel, or aluminum.

Our rolling service door is composed of curved or flat-faced slats that provide a natural water-shed, helping to reduce corrosion. The slats are designed with free-acting interlocking joints that permit easy articulation when the door coils.

Rolling Service Door features a strong double-angle bottom bar designed for easy installation and does not require fasteners protruding into the guide openings, so the bottom bar does not interfere with door operation.

Counterbalance assembly consists of a spring barrel which serves as a load-carrying beam. It encases the counterbalance mechanism and provides the axis around which the curtain coils. (Deflection is limited to 0.033" per lineal foot of span.)

Rolling Service Door is designed to meet the tough requirements of virtually any commercial or industrial application, with the added advantage of energy efficiency. The rolling service doors offers flexibility in substrate materials with choices of galvanized or primed steel, stainless steel or aluminum. This door is designed to withstand wind loads of up to ±20 psf standard, with optional wind load ratings of up to ±55 psf.

These insulated rolling service doors are composed of flat slats that provide a natural watershed, helping to reduce corrosion. Foamed-in-place polyurethane insulation with an R-value* of 7.7 fills the slat to enhance a building’s thermal efficiency. The slats are designed with free-acting interlocking joints that permit easy articulation when the door coils.

The doors features a strong double-angle bottom bar designed for easy installation and does not require fasteners in the guide openings, so the bottom bar does not interfere with door operation.

Distribution Centers   |   Storage Facilities    |   Commercial Buildings    |    Industrial Facilities    |    First Responder Facilities    |    Municipal Buildings    |    Retail Buildings    |    Manufacturing Plants    |    Production Facilities    |    Loading Docks    |

Max Width*            42’

Max Height*           40'

Max Steel Gauge: 16

Construction:        Steel, Aluminum or Stainless Steel

Slats Heavy-duty 3" flat or curved

Wind load Options: ±20 psf standard; options up to ±55 psf

Bottom Bar Double-angle bottom bar reinforces the lower edge of the curtain

• Curtain: steel, stainless steel, aluminum, G-90 galvanized
• Locking: slide bolts, cylinder, best lock, thumb turns
• Bottom bar: stainless steel double angle, structural steel angle construction (galvanized steel only), extruded aluminum, sloped
• Bottom edge: astragal, pneumatic or electric sensing edge
• Spring: up to 200k cycle, options available dependent on door size and weight
• Perimeter seals: angled guide brush seal, clip-on vinyl guide seal, exterior lintel weather seal, interior weather baffle
• End covers
• Fascia
• Drop stop device
• Pass door
• Vision slat

• Manual push up
• Crank (awning, wall)
• Chain hoist
• Motor
• Through wall

• Wind locks alternating or continuous with windbar
• Articulating Windlocks for Operational wind load
• Options available to meet up to Dade County – Florida Building Commission High Velocity Hurricane Zone (FBC HVHZ)
